XL6009 DC-DC Booster module supply module output is adjustable Super LM2577 step-up module

Name: XL6009 DC-DC Booster module supply module output is adjustable Super LM2577 step-up module
SKU: BSPZ66642
Price: 150 BDT
Availability: InStock

Category: Building Materials

SKU: BSPZ66642

Seller: Bdshopbz

Tk 105

Tk 150

30% OFF

0 review(s)

wide input voltage 3V ~ 32V, the best operating voltage range is 5 ~ 32V;● Wide output voltage 5V ~ 35V;● Built-in 4A high efficiency MOSFET switch, the efficiency of up to 94%; (LM2577 current of only 3A)● high switching frequency of 400KHz, you can use a small capacity of the filter capacitor that can buy very good results, smaller ripple, smaller. (LM2577 frequency is only 50KHz)

Select a color: *

Green

Call For Order : 09613-800800

XL6009 DC-DC Booster module Power supply module output is adjustable Super LM2577 step-up module ( When the module output voltage can not be adjusted, the output voltage is always equal to the input voltage.Please adjust the potentiometer counterclockwise 20 laps or more. (Let potentiometer against your chest, counterclockwise turn boost) ) Our products are independent research and development and production, sophisticated technology, each products are through strict test before sent to the user. And can meet the demand of batch. 32V - 3.2V input output highest 38V Output voltage range: 4V to 38V dc voltage continuously adjustable, high efficiency (96%) of the maximum output current for 4A. Advantage: use double thickening black oil PCB with high quality, all use imported SMD aluminum electrolytic capacitors, high Q value power inductors. And every piece of plate passes through the strict technical test, test completely using separate antistatic protection bag packaging. Note: Does this modules relative to the LM2577 triode mode conversion efficiency is higher Does this module is adjustable booster module, can by adjusting the precision of modules above circle more adjustable potentiometer To change the output voltage. The highest output voltage is 38 v. Chronological booster, reverse-time step-down. Does the module above marked GND (input), the IN + (input), GND (output), the OUT + (output) Does working temperature: : industrial grade 40 to + 85 (-) (ambient temperature more than 40 degrees, please reduce power use, or enhance heat dissipation) Package Included: 1pcs

wide input voltage 3V ~ 32V, the best operating voltage range is 5 ~ 32V;● Wide output voltage 5V ~ 35V;● Built-in 4A high efficiency MOSFET switch, the efficiency of up to 94%; (LM2577 current of only 3A)● high switching frequency of 400KHz, you can use a small capacity of the filter capacitor that can buy very good results, smaller ripple, smaller. (LM2577 frequency is only 50KHz)
