WirelessWireless Standards

IEEE 802.11 a/n/ac 5 GHz, IEEE 802.11 b/g/n 2.4 GHz

WiFi Speeds

867 Mbps on 5 GHz, 400 Mbps on 2.4 GHz

Reception Sensitivity

2.4 GHz:

11g 6Mbps:-96dBm

11g 54Mbps:-78dBm

11n HT20 MCS7:-76dBm

11n HT40 MCS7:-73dBm

5 GHz:

11a 6Mbps:-95dBm

11a 54Mbps:-77dBm

11ac VHT20 MCS8:-72dBm

11ac VHT40 MCS9:-67dBm

11ac VHT80 MCS9:-63dBm

Transmission Power

2.4 GHz < 20dBm (EIRP)

5 GHz < 23dBm (EIRP)

Wireless Security

WPA-PSK/WPA2-PSK

Mesh protocol

802.11k/v/r

HardwareDimensions

3.5 × 3.5 × 3.5 in (88 × 88 × 88 mm)

Interfaces

2× Gigabit Ports per Halo Unit

(WAN/LAN auto-sensing)

Button

Reset button

SoftwareOperation Mode

Router, Access Point

Quality of Service

WMM

WAN Type

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

Management

Local Management, Remote Management, Multi-Managers

Firewall Security

SPI Firewall

Protocols

Supports IPv4 and IPv6

Guest Network

2.4 GHz Guest Network x 1,

5 GHz Guest Network x 1

DHCP

Server, Client

OthersPackage Contents

3× Halo H30G Units

1× RJ45 Ethernet Cable

3× Power Adapters

1× Quick Installation Guide

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing
