| Panel Specification |
Quantum dot/ Wide colour gamut/ KSF phosphor |
Yes/ Yes / Yes |
| Display Technology |
LCD/ LED lit |
| Backlight source |
Direct LED |
| Aspect Ratio |
16:09 |
| Panel Size |
75inch/ 189cm |
| Display Resolution |
3840X2160 |
| Brightness |
350cd/m2 |
| Contrast Ratio |
1300 : 1 |
| Response Time |
8 ms |
| Viewing Angle |
178° / 178° |
| Color Depth |
8bit+FRC |
| Refresh Rate |
60 Hz |
| Motion Rate |
120 Hz |
| Basic Information |
TV System |
PAL; NTSC; SECAM |
| Power Supply |
100 ~ 240V,50Hz/60Hz |
| Power Consumption (STB) |
< 0.5W |
| Hardware Configuration |
CPU |
Quad Core |
| RAM |
2GB |
| ROM |
16GB |
| Software Configuration |
OS/UI Version |
Google TV (Android S) |
| Google Play Store |
Yes |
| Screen Mirroring |
DLNA / Chromecast / Miracast / AirPlay |
| OTA- Software updates |
Yes |
| Voice command |
Google Assistant/Far Field Voice Control |
| YouTube |
Yes |
| Netflix |
Yes |
| Amazon Prime |
Yes |
| Web Browser |
Odin |
| Sound |
Audio Power Output |
2 x 15 Watt |
| Audio equalizer |
Yes |
| Dolby Digital |
Yes |
| Audio enhancement |
Dolby ATMOS |
| Connectivity/ Terminals |
RJ45 (LAN Port) |
1 |
| Wi-Fi Protocol (IEEE 802.11) |
a, b, g, n, ac |
| Wi-Fi Bands |
2.4/5.0 GHz |
| Bluetooth / BT version |
Yes / 5.3 |
| Optical Digital Audio Out |
1 |
| HDMI In |
3 |
| AV In |
1 |
| AUDIO Out ( 3.5 mm)/ Earphone Jack |
1 |
| RF In |
1 |
| USB 2.0 |
2 |
| Dimensions & Weight |
Dimensions with stand (W x H x D) |
1676×1004×360mm |
| Dimensions without stand (W x H x D) |
1676×966×87mm |
| Carton box dimensions (W x H x D) |
1865×1146×210mm |
| Net weight (with stand / without stand) |
22.5kg /22.2kg |
| Gross weight |
32kg |
