asic Specifications

Ai Conditioner Function

Cooling

Cooling Capacity (BTU/h)

12000

Cooling Capacity (W)

3517

Rated Voltage (V)

220-240V, 50 Hz

Rated Input Power (W)

1030

Rated Current (A)

4.80

Climate Class

T1

EER (W/W)

3.20

Noise Level (dB) Indoor (Mid Fan Speed)

35

Noise Level (dB) Outdoor

51

Connecting Pipe Length (m)

4

Cooling Specifications

Refrigerant

R32

Refrigerant Amount (kg)

0.600

Evaporator Type

Copper Tube Evaporator

Condenser Type

Copper Tube Condenser

Evaporator Fin Type

Golden Hydrophilic Fin

Condenser Fin Type

 Golden Hydrophilic Fin

Compressor Type

Rotary

Operating Features

Temperature Control Range

16°C-30°C

Display Type (Indoor)

LED

Display Dimmer

YES

Vertical Auto Swing Louver

YES

Horizontal Auto Swing Louver

YES

Indoor Unit Filter

Washable PP Filter

24 Hour Timer

YES

Sleep Operation

YES

Super Function

YES

Auto Restart

YES

Refrigerant Leak Detection

YES

Operation/Control

Wirelesss Remote Controlled

3 Speed and Auto  Indoor Fan Control

YES

WIFI

No

Packing Information

Indoor Unit Net Dimension (LxWxH) mm

795×256×197

Indoor Unit Packing Dimension (LxWxH) mm

850×320×260

Outdoor Unit Net Dimension (LxWxH) mm

715×540×240

Outdoor Unit Packing Dimension (LxWxH) mm

830×588×340

Indoor unit Net Weight (kg)

7.5

Indoor unit Gross Weight (kg)

9.2

Outdoor unit Net Weight (kg)

26

Outdoor unit Gross Weight (kg)

30
