UNI-T UT513A Insulation Resistance Tester 5kV, USB Interface

Name: UNI-T UT513A Insulation Resistance Tester 5kV, USB Interface
SKU: 01144
Price: 38000 BDT
Availability: InStock

Category: Building Materials

SKU: 01144

Seller: Kings Trading

Tk 34960

Tk 38000

8% OFF

0 review(s)

Call For Order : 09613-800800

UT513A Insulation Resistance Tester

UT510 series testers can measure insulation resistance of large transformers, generators, high-voltage motors and more. UT510 series can also measure PI, DAR and other important specifications. Measured data can then be analyzed through PC software. UT513A can produce test voltage up to 5kV.

Product description
Introduction
UT513A is an auto range digital insulation resistance tester with 30 analogue bar graph, AC/DCV test, low battery indication and secondary display.
Specification
Model: UT513A
Insulation Resistance (Ω)
Test Voltage: 500V/1000V/2500V/5000V 0%～20%
500V: 0.5MΩ~20GΩ ±(3%+5)
1000V: 1.0MΩ~40GΩ ±(3%+5)
2500V: 2.5MΩ~100GΩ ±(3%+5)
5000V: 5.0MΩ~1000GΩ ±(3%+5)
Short Circuit Current: >3.0mA
DC Voltage (V): 600V ±(2%+3)
AC Voltage (V): 600V ±(2%+3)
Features
Auto Range: √
Auto Power Off: √
Secondary Display: √
Low Battery Indication: √
Data Storage: 18
Comparison: √
DAR: √
PI: √
USB Interface: √
LCD Backlight: √
Analog Bar Graph: 30
Overload Indication: √
High Voltage Indication: √
Timer: Around 15 Minutes
General Characteristics
Power: 1.5V Batteries (LR14) x 8
LCD Size: 123mm x 58mm
Product Color: Red and grey
Product Weight: 2kg
Product Size: 202mm×155mm×94mm
