• Rectification: Non-Synchronous Rectification
• Input Range: 3V ~ 32V
• Output Range: 5V ~ 35V
• Input Current: 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.)
• Conversion Efficiency: <94% (greater the pressure, the lower the efficiency)

Input Current: 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.)
Conversion Efficiency: <94% (greater the pressure, the lower the efficiency)
Switching Frequency: 400KHz
Output Ripple: 50mV (the higher the voltage, the greater the current, the greater the ripple)
Load Regulation: ± 0.5%
Voltage Regulation: ± 0.5%
Operating Temperature: -40° C ~ +85° C
