XH-M601 Battery Charging Control Board 12V Intelligent Charger Power Supply Control Module Panel Automatic Charging/Stop Power - solar charge controller (Multicolor)

Category: Battery & Charger
SKU: PONS841804
Seller: Ponno shopping
Tk 220
Tk 450
Tk 450
51% OFF
0 review(s)
  • Name:12V charger power control board
  • Model:XH-M601
  • Power Supply Voltage:13.8-14.8V
  • Relay Operating Voltage:12.4V
  • Relay Disconnect Voltage:14.8V
  • Voltage Tolerance:+/-0.1V
  • Voltage Detection Way:DC voltmeter
  • Charging Type:12V storage battery
  • Potentiometer Adjustment:RP1 RP2
  • 10.Size:50*32*18mm
  • Potentiometer Adjustment:
  • RP1:adjust storage battery start charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)
  • RP2:adjust storage battery disconnect charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)

Call For Order : 09613-800800

XH-M601 Battery Charging Control Board 12V Intelligent Charger Power Supply Control Module Panel Automatic Charging/Stop Power
  • Name:12V charger power control board
  • Model:XH-M601
  • Power Supply Voltage:13.8-14.8V
  • Relay Operating Voltage:12.4V
  • Relay Disconnect Voltage:14.8V
  • Voltage Tolerance:+/-0.1V
  • Voltage Detection Way:DC voltmeter
  • Charging Type:12V storage battery
  • Potentiometer Adjustment:RP1 RP2
  • 10.Size:50*32*18mm
  • Potentiometer Adjustment:
  • RP1:adjust storage battery start charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)
  • RP2:adjust storage battery disconnect charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)





  • Name:12V charger power control board
  • Model:XH-M601
  • Power Supply Voltage:13.8-14.8V
  • Relay Operating Voltage:12.4V
  • Relay Disconnect Voltage:14.8V
  • Voltage Tolerance:+/-0.1V
  • Voltage Detection Way:DC voltmeter
  • Charging Type:12V storage battery
  • Potentiometer Adjustment:RP1 RP2
  • 10.Size:50*32*18mm
  • Potentiometer Adjustment:
  • RP1:adjust storage battery start charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)
  • RP2:adjust storage battery disconnect charging voltage (low voltage setting:clockwise becomes higher,counter-clockwise becomes lower)
