Brand: Uniview

Model: XVR301-16Q3

Product Type: XVR

Form Factor: Rack

Body Color: Black

Chassis: 1U

Video Input Channel: 8-Ch

Analog Video Input: 16-Ch, BNC

CVBS Input: PAL/NTSC

HDMI Output: 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz

VGA Output: 1920x1080/60Hz, 1920x1080/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz

Audio Input: 1-Ch via RCA

Audio Output: 1-Ch, RCA (Linear, 1 KΩ)

Two-Way Audio: Supported via First Audio Input

Synchronous Playback:

HD:8-Ch

SD:16-Ch

Video Compression: H.265+/H.265/H.264+/H.264

Resolution: 5MP Lite/4MP Lite /1080P Lite/720P/D1/CIF

Frame Rate:5MP Lite at 6fps, 4MP Lite at 8fps, 1080P Lite at 12fps, and 720P at 12fps

Video Bitrate: 32 Kbps to 8 Mbps

Dual-Stream: Supported

Stream Type: Video, Video & Audio

Audio Compression: G.711u

Audio Bitrate: 64 Kbps

Synchronous Playback:

HD:8-Ch

SD:16-Ch

Live View Window Division: 1/4/9/16

Network Protocol: TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP

Remote Connection: 128

Total Bandwidth: 40 Mbps (Incoming), 64Mbps (Outgoing)

API: ONVIF (profile S), SDK

Network Port: 1 × RJ-45 (10/100 Mbps Ethernet port)

Serial Interface: RS-485

USB Interface: Rear Panel: 2 x USB2.0

Alarm In/Out: Motion Detection

HDD Interface: 1 SATA ports

Capacity: Up to 8 TB

Facial Recognition: Ultra Motion Detection (UMD) , SIP (Intrusion Detection,

Cross Line Detection, Enter Area, Leave Area), Face Detection

Perimeter Protection: Face Detection, SIP(Intrusion Detection,

Cross Line Detection,Enter Area,Leave Area), Defocus Detection,

Object Removed, Object Left Behind, Auto Tracking

Power Supply: 12 VDC, 2 A

Consumption: ≤ 10 W (without HDD)

Speciality:

Supports 5 MP Resolution for Higher-quality Video Inputs

Certification: UL, CE, FCC, RoHS, WEEE

Dimensions: 260 × 226 × 47 mm

Weight: ≤ 1.1 kg

Warranty: 1 Year

Made in: China
