Scope of application: pressure is 0.05-1.0MpaMaterial: Aluminum alloy castingNet weight 215gGuaranteed pressure resistance: 1.5MPa (15.3kgf / cm2)Maximum working pressure: 1.0MPa (10.2kgf / cm)Environment and fluid temperature: 5 ~ 60 degrees CelsiusPressure regulation range: 0.05 ~ 0.85MPa (0.51-8.7kgf / cm)Rated flow (L / min): 550Service connection caliber Rc (PT): 1/4Pressure gauge Caliber Rc (PT): 1/8

• Scope of application: pressure is 0.05-1.0Mpa
• Material: Aluminum alloy casting
• Net weight 215g
• Guaranteed pressure resistance: 1.5MPa (15.3kgf / cm2)
• Maximum working pressure: 1.0MPa (10.2kgf / cm)
• Environment and fluid temperature: 5 ~ 60 degrees Celsius
• Pressure regulation range: 0.05 ~ 0.85MPa (0.51-8.7kgf / cm)
• Rated flow (L / min): 550
• Service connection caliber Rc (PT): 1/4
• Pressure gauge Caliber Rc (PT): 1/8
