iP5356 Power Bank Circuit With Case For Making 10K mAh Power Bank Diy ( Without Battery) Black

Specifications:

USB output fast charging protocol (support

QC3.0/QC2.0/AFC/FCP/SCP/DASH/WRAP/VOOC) (output 5V/3A 9V/2A 12V/1.5A 5V/4.5A 4.5V/5A)

Type-C support PD3.0/PD20/OC30/0C20/AFC/FCP/SCP/QC/DASH/WRAP/VOOC)

input (output 5V/3A9V/22A12V/1.5A5V/4.5A 4.5V/5A), (input 5V/3A 9V/2A12V/1.5A)

Micro input support AFC/FCP fast charging input (input

5V/2A9V/2A)

Short circuit protection: <50uS

Self-dissipation: Max 150uA

Discharge constant current: 5V3A

Recovery condition: Disconnect the load

Suggested operating conditions: 5V3A

Suggested operating temperature: -5~45°C

Charging input voltage: 4.5~5V

Constant charging voltage: 4.00-4.2V

Termination charging voltage: 4.2+0.05V
