Brand: Gigabyte
Model: H310M M.2
Product Type: Desktop Motherboard
Form Factor: Micro-ATX
Body Color: Black
Chipset: Intel H310
Sockets Supported: LGA1151
CPU Supported: 8th and 9th Gen Intel Core i9 / i7 / i5 / i3 / Pentium / Celeron processors
Memory Type: DDR4
Memory Speed (MHz): 2666+(OC) MT/s Memory Modules
Memory Slot: 2
Memory Max: 32GB
HDD Interface: SATA
HDD Slot: 4
SSD Interface: M.2
SSD Slot: 1
Graphics Chipset: Intel HD Graphics Support
Expansion Slots: 1 x PCI Express x16 Slot
Chip: Realtek GbE LAN chip (10/100/1000 Mbit)
Ethernet LAN: 10/100/1000Mbps
USB:
4 x USB 3.1 Gen 1 ports
6 x USB 2.0/1.1 ports
HDMI Port: 1
VGA Port: 1
RJ-45 Ports: 1
TPM Port: 1
Audio Jack: 3
BIOS Type: 1 x 128 Mbit Flash
BIOS Model: AMI UEFI BIOS
Power Consumption: 60W
Dimensions: 22.6 x 17.5 x 4.5cm
Weight: 0.7Kg
Warranty: 3 Years
Country Of Origin: Taiwan
Made in: China
Support Intel 9th and 8th Generation Core Processors
Intel GbE LAN chip (10/100/1000 Mbit)
Ultra-Fast M.2 with PCIe Gen2 X2 & SATA interface
2 x DDR4 DIMM sockets supporting up to 32 GB
3 Years Official Warranty
Warranty: 3 Years warranty.
Note: Product delivery duration may vary due to product availability in stock.
Disclaimer: The actual color of the physical product may slightly vary due to the deviation of lighting sources, photography or your device display settings.
