Description

AM2301 Capacitive Digital Temperature & Humidity Sensor sensor is one of the commonest from the range of DHT temperature sensors; and boasts a relatively high-temperature measurement accuracy of 0.5°C in 0.1°C steps with a relative humidity accuracy of ± 3%. Dishan Tech BD.

It has only 3 wires, including power and ground, meaning only one digital pin is required to interface it to a microcontroller. For Arduino development platforms the sensor is very well supported by the DHT library available from the Arduino Playground website. Featured By Dishan Tech BD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

Dishan Tech BD.

Features:

1. 4-pin package.
2. Ultra-low-power.
3. No additional components. Dishan Tech BD.
4. Excellent long-term stability.
5. All calibration, digital output.
6. Completely interchangeable.
7. Long-distance signal transmission.
8. Relative humidity and temperature measurement.

Specifications:

1. Model: AM2301 Dishan Tech BD.
2. Power supply: 3.3-5V DC
3. Output signal: digital signal via single-bus
4. Sensing element: Polymer humidity capacitor
5. Measuring range: humidity 0-100%RH; temperature -40~80Celsius
6. Accuracy: humidity +-3%RH(Max +-5%RH); temperature <+-1Celsius
7. Resolution or sensitivity: humidity 0.1%RH; temperature 0.1Celsius
8. Repeatability: humidity +-1%RH; temperature +-0.2Celsius
9. Humidity hysteresis: +-0.3%RH
10. Long-term Stability: +-0.5%RH/year
11. Sensing period: Average: 2s
12. Dimensions size 59*27*13.5mm

Dishan Tech BD.

Please allow 5% measuring deviation due to manual measurement.

Dishan Tech BD.

Documentation:

1. DHT21 AM2301 Temperature & Humidity Sensor (HCSENS0026)
2. Humidity and Temperature

–

Package includes:

1 x DHT21 AM2301 Temperature & Humidity Sensor.

Dishan Tech BD.

What is the price of DHT21 AM2301 Temperature & Humidity Sensor in Bangladesh?

The latest price of DHT21 AM2301 Temperature & Humidity Sensor in Bangladesh is BDT 599 You can buy the DHT21 AM2301 Temperature & Humidity Sensor at best price from our Dishan Tech BD.or visit Dishan Tech BD.
