DC 12V 3 Way 2 Position Pneumatic Electric Solenoid Valve

Name: DC 12V 3 Way 2 Position Pneumatic Electric Solenoid Valve
SKU: MTBD659335
Price: 880.00 BDT
Availability: InStock

Category: Tools

SKU: MTBD659335

Seller: MACHINE & TOOLS BD

App Coupon to Get Extra Discount

Tk 880

Standard Specification
Model	3V210-08	Biggest Withstanding Pressure	12kgf/c㎡
Working Medium	Air(40 micron cleaned)	Power Consumption	DC12V:2.5
Motion Pattern	Internal Pilot	Protection Class	IP65(DIN40050)
Adapter's	Air-in=Air Out=PT1/8 Air-in=Air Out=PT2/8 Air-in=Air Out=PT3/8	Electrifying Model	Box Type
The Position Countion	Three-mouth Two-position	Body Material	Al Alloy
Ambient Temperature	-5~60℃(23~140)℉	Highest Action Frequency	5/sec
Effective Section Area	14㎡(Cv=0.78) 16㎡(Cv=0.89) 25㎡(Cv=1.39) 30㎡(Cv=1.67)	Insulation	Class F
Lube Cation	No Required	Voltage Range	-15%~+10%
Working Pressure	1.5~8.0 kgf/c㎡	Response Time	0.05s

Select Color: *

Standard Specification
Model	3V210-08	Biggest Withstanding Pressure	12kgf/c㎡
Working Medium	Air(40 micron cleaned)	Power Consumption	DC12V:2.5
Motion Pattern	Internal Pilot	Protection Class	IP65(DIN40050)
Adapter's	Air-in=Air Out=PT1/8 Air-in=Air Out=PT2/8 Air-in=Air Out=PT3/8	Electrifying Model	Box Type
The Position Countion	Three-mouth Two-position	Body Material	Al Alloy
Ambient Temperature	-5~60℃(23~140)℉	Highest Action Frequency	5/sec
Effective Section Area	14㎡(Cv=0.78) 16㎡(Cv=0.89) 25㎡(Cv=1.39) 30㎡(Cv=1.67)	Insulation	Class F
Lube Cation	No Required	Voltage Range	-15%~+10%
Working Pressure	1.5~8.0 kgf/c㎡	Response Time	0.05s

Standard Specification
Model	3V210-08	Biggest Withstanding Pressure	12kgf/c㎡
Working Medium	Air(40 micron cleaned)	Power Consumption	DC12V:2.5
Motion Pattern	Internal Pilot	Protection Class	IP65(DIN40050)
Adapter's	Air-in=Air Out=PT1/8 Air-in=Air Out=PT2/8 Air-in=Air Out=PT3/8	Electrifying Model	Box Type
The Position Countion	Three-mouth Two-position	Body Material	Al Alloy
Ambient Temperature	-5~60℃(23~140)℉	Highest Action Frequency	5/sec
Effective Section Area	14㎡(Cv=0.78) 16㎡(Cv=0.89) 25㎡(Cv=1.39) 30㎡(Cv=1.67)	Insulation	Class F
Lube Cation	No Required	Voltage Range	-15%~+10%
Working Pressure	1.5~8.0 kgf/c㎡	Response Time	0.05s
