Specifications
Brand: Dahua
Model: DH-IPC-HDW1230T1-A
Image Sensor: 1/2.8" CMOS
Effective Pixels: 1920(H) x1080(V), 2MP
Scanning System: Progressive
S/N Ratio: 65dB
IR Distance: Distance up to 25m
Lens Type: Fixed -Focal
Mount Type: M12
Focal Length: 2.8mm; 3.6mm
Max Aperture: 2.8 mm: F2.0; 3.6 mm: F2.0
Angle of View: 2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°; 3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°
Focus Control: Iris Control: Fixed
Resolution: 1080p (1920 × 1080); 1.3M(1280 × 960);720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Frame Rate: Main Stream: 1920 × 1080 (1 fps–25/30 fps); Sub stream: 704 × 576 (1 fps–25 fps), 704 × 480 (1 fps–30 fps)
Video Output: Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Day/Night: Auto (ICR)/Color/B/W
BLC Mode: BLC, WDR, HLC
Gain Control: Auto/Manual
Noise Reduction: 3D NR
Network: RJ-45 (10/100 Base-T)
ROM: 16 MB
RAM: 64 MB
Max. power consumption: 3.3W (12V DC)
Power Supply: 12 V / PoE (802.3af)
Weight: 0.24 kg
Dimensions: 85.5 mm × Φ109 mm
Warranty: 1 Year

Warranty: 1 Year warranty.
Note: Product delivery duration may vary due to product availability in stock.

Disclaimer: The actual color of the physical product may slightly vary due to the deviation of lighting sources, photography or your device display settings.
