Description

CR-M4 boasts a massive build volume of 450*450*470mm. It’s a real workhorse to create big models with less or no post-processing or to batch-print more parts in one go.

Precise and Reliable Dual Y-axis Linear Rails

Start a Print Farm with More Printers

“When many CR-M4 printers are online, it is easy to start a 3D print farm for volume production, where the printers produce the same model on a single command from Creality Print or Creality Cloud Web.

Always a Handy Way of Printing

With a LAN connection, users can print from any PC on the LAN by using Creality Print. With an Internet connection, users can print and monitor remotely from the Creality Cloud APP or Web.

Raise the Bar of Printhead Specs

Diverse Filaments to Realize Bold Ideas

The superb all-rounder printhead gives the liberty to print with PLA, PA (nylon), heat-resistant ABS, PLA-Wood, PLA-CF, flexible TPU, and PETG.

Genuine 25-point Auto-Leveling

Fully automatic leveling with CR Touch by probing 25 points, and Z offset at 0.05mm accuracy to quickly calibrate the distance between the nozzle and the build surface.

Flexible PC Surface and Fast-heating Bed

A 4-layered build platform. The PC coating provides strong adhesion. The bendable spring steel sheet is easy to remove in large models and will not deform after long-term use. The magnetic base and two pins allow quick snap-on.

Less Wobbling with Rigid Z-axis

“The dual Z-axis curb gantry sagging and Z-wobbling. Together with the 2 support rods, a rigid triangle is formed to stabilize the top frame. Each Z-axis is driven by a standalone motor for neat movement. Now, the quality of tall models is ensured from bottom to top.”

Printing Technology: FDM

Build Volume: 450*450*470mm

Product Dimensions: 655*700*865mm

Package Dimensions: 790*760*300mm

Net Weight: 22.48KG

Gross Weight: 28.3KG

Printing Speed: ≤120mm/s

Printing Accuracy: ±0.1mm

Layer Height: 0.05-0.35mm

Extruder Type: “Sprite” dual-gear direct drive extruder

Extruder Material: All metal

Filament Diameter: 1.75mm

Z-axis Count: 2

Nozzle Type: Brass nozzle

Nozzle Diameter: Standard 0.4mm (compatible with 0.6/0.8mm)

Nozzle Temperature: ≤300°C

Heatbed Temperature: ≤100℃

Build Surface: PC spring steel sheet

Display Screen: 4.3-inch color touch screen

Mainboard: Integrated 32-bit silent mainboard

Power Loss Recovery: Yes

Filament Runout Sensor: Yes

Multi-printers Control: Yes

Sleep Mode: Yes

Rated Voltage: 100-240V~，50/60Hz

Rated Power: 800W

Slicing Software: Creality Print, Creality Slicer, Cura

File Formats: STL, OBJ, AMF

Supported Filaments: PLA, PETG, TPU, ABS, PLA-Wood, PA, PLA-CF

UI Languages: English, Spanish, German, French, Russian, Portuguese, Italian, Turkish, Chinese
