Specification

Brand: Biostar

Model: H510MHP

Chipset: Intel H510

CPU Support: Socket 1200 for 10th / 11th Gen Intel Core™, Pentium and Celeron processors

Memory: Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200; 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory; Each DIMM supports non-ECC 4/8/16/32GB DDR4 module

Integrated Video: Supports DX12; Supports HDCP

Storage: 4 x SATA III Connector (6Gb/s);1 x M.2 (M Key) Socket; Supports M.2 Type 2242/ 2260/ 2280 SSD module; Supports PCIe 3.0 x 4 (32Gb/s) & SATA III (6Gb/s) SSD

LAN: Intel I219V; 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

Audio Codec: Realtek ALC887; 7.1 Channels, High Definition Audio

USB: 4 x USB 3.2(Gen1) ports (2 on rear I/Os and 2 via internal headers); 6 x USB 2.0 ports (4 on rear I/Os and 2 via internal headers)

Expansion Slot: 2 x PCIe 3.0 x1 Slot; 1 x PCle 3.0/4.0 x16 Slot

Rear I/O:

- 1 x PS/2 Keyboard

- 1 x PS/2 Mouse

- 1 x HDMI Port

- 1 x VGA Port

- 2 x USB 3.2 (Gen1) Ports

- 4 x USB 2.0 Ports

- 1 x LAN port

- 3 x Audio Jack

Internal I/O:

- 4 x SATA III Connectors (6Gb/s)

- 1 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

- 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

- 1 x 8-Pin Power Connector

- 1 x 24-Pin Power Connector

- 1 x CPU Fan Connector

- 1 x System Fan Connector

- 1 x Front Panel Header

- 1 x Front Audio Header

- 1 x Clear CMOS Header

- 1 x COM Port Header

OS Support: Supports Windows 10 (64bit) / 11(64bit)

Dimension: 18.5cm x 22.6cm

Warranty: 3 Years
