Asus PRIME B660M-K DDR4 12th Gen Motherboard

Name: Asus PRIME B660M-K DDR4 12th Gen Motherboard
SKU: JACO712132
Price: 17140.00 BDT
Availability: InStock

Category: Computers, Components & Accessories

SKU: JACO712132

Seller: Janani Computers

App Coupon to Get Extra Discount

Tk 17,140

0 review(s)

Asus PRIME B660M-K Gaming DDR4 12th Gen Motherboard

Dual Ultra-Fast PCIe 4.0 x4 M.2
LGA1700 CPU Socket
64 GB Max Memory
Supports 12th Gen Intel Core Series Processors
3-years Official Brand Warranty

Call For Order : 09613-800800

SpecificationsBrand: ASUS
Series: PRIME B660M
Model: B660M-K
Chipset: Intel H610
CPU: Intel Core Socket LGA1700 12th Gen , Pentium Gold and Celeron processors
Memory Channels: Dual Channel
Max Memory: 64GB
Memory slots: 2 x DIMM
Supported Memory: 5333(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
Bios: 128 Mb Flash ROM, UEFI AMI BIOS
HDMI: 1 x HDMI
Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC, Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, Supports up to 24-Bit/192 kHz playback
D-Sub Port: 1 x D-Sub,
Expansion Slots:-
Intel 12th Gen Processors
1 x PCIe 4.0/3.0 x16 slot
Intel B660 Chipset
2 x PCIe 3.0 x1 slots
Storage:-
Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel 12th Gen Processors
M.2_1 slot (Key M), type 2242/2260/2280
Intel 12th Gen processors support PCIe 4.0 x4 mode.
Intel B660 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4)
4 x SATA 6Gb/s ports
Back Panel I/O Ports:-
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x D-Sub port
1 x HDMI port
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors
Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chassis Fan header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Miscellaneous
1 x RGB header
1 x Clear CMOS header
1 x COM Port header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x SPI TPM header (14-1pin)
1 x 10-1 pin System Panel header
USB:-
2 USB 3.2 Gen 2 ports (2 x Type-A)
2 USB 3.2 Gen 1 ports (2 x Type-A)
2 USB 2.0 ports (2 x Type-A)
1 USB 3.2 Gen 1 connector (supports USB Type C)
1 USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 USB 2.0 headers support additional 4 USB 2.0 ports
Ethernet: 1 x Realtek 1Gb Ethernet
Cables: 2 SATA 6Gb/s cables
Form Factor: microATX 24.4cm x 21.1cm
Warranty: 3 Years Brand Warranty

Asus PRIME B660M-K Gaming DDR4 12th Gen Motherboard

Dual Ultra-Fast PCIe 4.0 x4 M.2
LGA1700 CPU Socket
64 GB Max Memory
Supports 12th Gen Intel Core Series Processors
3-years Official Brand Warranty

Warranty: 3 Years warranty.
