CPU:

AMD AM4 Socket forAMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors ** Refer tofor CPUsupport list

Chipset:

AMD A520

Memory:

4 x DIMM, Max. 128GB,DDR44800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133MHz Un-buffered Memory *Dual Channel Memory ArchitectureECC Memory (ECC mode) support varies by CPU.* Refer tofor theMemory QVL (Qualified Vendors Lists).* The maximum memory frequency supported varies by processor.

Graphic:

1 x D-Sub1 x DVI-D1 x HDMI 2.1(4K@60HZ)

Expansion Slots:

AMD Ryzen™ 5000Series/ 4000 G-Series/ 3000 Series Desktop Processors1 x PCIe 3.0 x16 (x16 mode)2 x PCIe 3.0 x1

Storage:

Total supports 1 xM.2 slot(s) and 4 x SATA 6Gb/s portsAMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors:AMD A520 Chipset :

LAN:

Realtek RTL8111H 1GbEthernetASUS LANGuard

Audio:

Realtek ALC887/8977.1 SurroundSound High Definition Audio CODEC *- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to24-Bit/192kHz playback- LED-illuminated design- Audio Shielding- Dedicated audio PCB layers- Premium Japanese audio capacitors* Choose the chassis with HD audio module in front panel to support 8-channelaudio output.

USB Ports:

RearUSB Port(Total 6 )4 x USB 3.2 Gen 1 port(s)(4 x Type-A)2 x USB 2.0 port(s)(2 x Type-A)( Total 6 )2 x USB 3.2 Gen 1 port(s)(2 x Type-A)4 x USB 2.0 port(s)(4 x Type-A)

Software Features:

ASUSExclusive SoftwareArmoury CrateAI Suite 3- Performance And Power Saving UtilityTurboV EVOEPUDigi+ VRMFan Xpert 2+- Lighting Control- EZ updateASUS CPU-ZAI ChargerDAEMON ToolsNorton Anti-virus software (Free Trial for 60 days)WinRARUEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode

ASUS SpecialFeatures:

ASUS5X PROTECTION III- ASUS DIGI+ VRM- ASUS LANGuard- ASUS Overvoltage Protection- ASUS SafeSlot Core- ASUS Stainless-Steel Back I/OASUS Q-Design- ASUS Q-DIMM- ASUS Q-SlotASUS Thermal Solution- Aluminum heatsink design

Back I/O Ports:

1x PS/2 keyboard/mouse combo port(s)1 x DVI-D1 x D-Sub1 x HDMI1 x LAN (RJ45) port(s)4 x USB 3.2 Gen 1 (blue) Type-A2 x USB 2.03 x Audio jack(s)

Internal I/OPorts:

1x CPU Fan connector(s)2 x Chassis Fan connector(s)1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen1 port(s)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support(SATA & PCIE 3.0 x 4 mode)1 x SPI TPM header4 x SATA 6Gb/s connector(s)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 8-pin EATX 12V Power connectors1 x Front panel audio connector(s) (AAFP)1 x Clear CMOS jumper(s)1 x System panel connector1 x COM port header

Accessories:

User´smanualI/O Shield2 x SATA 6Gb/s cable(s)1 x Supporting DVD1 x M.2 SSD screw package(s)

BIOS:

256Mb Flash ROM, UEFI AMI BIOS

Manageability:

WOLby PXE

Operating System:

Windows®10 64-bit

Form Factor:

mATX Form Factor9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
