1. Supported CPU:

   • Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold, and Celeron Processors.
   • Supports Intel 14 nm CPU.
   • Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0.
   • Supports CPU up to 125 W.

2. Chipset: Intel B560.

3. BIOS: 128 Mb Flash ROM, UEFI AMI BIOS.

4. Form Factor: mATX Form Factor measuring 8.9 inches x 8.3 inches (22.6 cm x 21.1 cm).

5. Audio:

   • Realtek ALC897 7.1 Surround Sound High Definition Audio CODEC.
   • Supports various audio features including Jack-detection, Multi-streaming, Front Panel Jack-retasking.
   • Supports up to 24-Bit/192 kHz playback.
   • Audio Features include Premium Japanese audio capacitors, Audio Shielding, Dedicated audio PCB layers.

6. Expansion Slots:

   • PCIe 3.0/2.0 x16 slot for Intel 10th Gen Processors.
   • 2 x PCIe 3.0 x1 slots.
   • M.2_1 slot (Key M) supports type 2242/2260/2280.
   • M.2_2 slot (Key M) supports type 2242/2260/2280.

7. Memory:

   • Dual Channel Memory Architecture.
   • 2 x DDR4 DIMM slots.
   • Supports DDR4 memory up to 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz.
   • Supports Intel Extreme Memory Profile (XMP).
   • Maximum memory support of 64 GB.

8. Graphics:

   • 1 x D-Sub.
   • 1 x HDMI 1.4 / 2.0.
   • Supports various resolutions depending on the processor generation.

9. Connector & Ports:

   • Rear USB: 4 x USB 3.2 Gen 1 ports, 2 x USB 2.0 ports.
   • Front USB: 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports, 2 x USB 2.0 headers support additional 4 USB 2.0 ports.
   • LAN Port: 1 x Realtek 1Gb Ethernet with ASUS LANGuard.
   • Supported Storage: Supports 2 x M.2 slots and 4 x SATA 6Gb/s ports.
   • TPM (Trusted Platform Module): 1 x SPI TPM header.

10. Internal I/O Ports:

    • Various connectors including CPU Fan, Chassis Fan, AAFP, USB connectors, M.2 Socket, SATA connectors, S/PDIF out header, Power connectors, Front panel connector, COM Debug header, Clear CMOS jumper, TPM header.

11. Special Features:

    • ASUS 5X Protection III.
    • Non-stop Durability with features like Anti-moisture coating, USBGuard.
    • Non-stop Gaming features with Dedicated audio PCB layers, Premium Japanese audio capacitors.
    • Non-stop Challenger with ASUS iCafe Labs Certified.

12. Warranty Information: 3 Years Manufacturing Warranty.

Warranty: 3 Years warranty.
Note: Product delivery duration may vary due to product availability in stock.

Disclaimer: The actual color of the physical product may slightly vary due to the deviation of lighting sources, photography or your device display settings.
