Brand: Apollo

Model: 2300HS

Color: Black

Body Material: Metal

Type: Online UPS

Input Voltage: Single Phase, 110Vac~ 290Vac

Input Frequency: 50 Hz (60 Hz on request) ± 5%

Power factor: > 0.98% (full load)

Output Voltage: 220Vac

Output Voltage Regulation: 220Vac ± 0.5%

Output Transient Response: ± 3~4% under full load, change and corrected within 2 ms

Wave form: Pure Sinewave THD<3%

Power factor: 0.8

Frequency: 50 / 60Hz, ± 0.5%

Crest Factor: 3:1

Overload: Continuous alarming, switch to bypass, auto recovery upon removing of load

Overload Capacity: <110% load Continuous, 110-125% load 12 Minutes, 125-150% load 10 Minutes, >150% load: by pass

Battery Type: Maintenance free lead-acid batteries

DC Voltage: 96VDC

Backup time: 15-30 minutes depending on load

External Battery: Up to 8 hours long time backup depends on external battery

Supplementary Charger: Optional 200W/500W charger for extended back-up application

Recharge time: 5~8 hours

Cold Start: Yes, UPS cab be started without AC source

Protections: High Voltage, Overload, Overheating, bypass, Short circuit, Noise Filtering, Spike, Surge

EMI Filter: 10~100 KHz at 40dB, 100KHz~100MHz at 70Db

Dimension: 48.5 x 45.0 x 19.0cm

Warranty Details: 1 Year (Box Mandatory While Claiming)
