Specification

Data Rate

10/100

Button

1

Frequency

650 MHz

Interface

Architecture MIPSBE

CPU QCA9531

CPU core count 1

License level 4

Size of RAM 64 MB

Storage size 16 MB

Storage type FLASH

Ports

PoE-out ports: Ether2-Ether5

Number of USB ports 1

Others

Current Monitor Yes

PCB temperature monitor Yes

Voltage Monitor Yes

Tested ambient temperature -40°C to 70°C

USB Power Reset Yes

Operating System Support

Operating System RouterOS

Power Source

Power Mode

PoE in: Passive PoE

PoE in input Voltage: 8-30 V

PoE out: Passive PoE

PoE-out ports: Ether2-Ether5

Number of DC inputs: 2 (PoE-IN, DC jack)

DC jack input Voltage: 8-30 V

Max out per port output (input < 30 V): 1 A

Max total out (A): 2 A

Max power consumption: 51 W

Max power consumption without attachments: 3 W

Physical Dimension

Shell Color

White

Dimension

113x89x28mm
