- Camera
- Image Sensor3K CMOS
- Signal System PAL/NTSC
- Resolution2960 (H) × 1665 (V)
- Frame Rate TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps
- Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
- Lens2.8 mm, 3.6 mm fixed focal lens
- Field Of View 3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96°
- Lens MountM12
- Light Alarm Solid Light Alarm (White Light)
- Day & Night24/7 Color Imaging
- WDR (Wide Dynamic Range)Digital WDR
- Angle Adjust ment Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Image
- White Light Auto/Off
- Image Model STD/HIGH-SAT/HIGHLIGHT
- AGC Yes
- Day/Night Model Color
- White Balance Auto/Outdoor/Global/Manual
- AE (Auto Exposure) Model DWDR ;BLC; HLC; Global; HLS
- Noise Reduction2D DNR
- Language English
- Function Defective Pixel Correction;Sharpness;Mirror;Contrast;Brightness;Anti-Banding;Smart Light
- Interface
- Video Output Switchable TVI/AHD/CVI/CVBS
- Audio In Built-in mic
- General
- Operating Conditions-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply
- Consumption Max. 2.5 W
- Protection LevelIP67
- Material Metal
- White Light Range Up to 20 m
- Communication HIKVISION-C
- Dimension161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
- Weight Approx. 404 g (0.89 lb.)
