5V 5-Pin Relay Power 10A (5pcs) (Silver)

Name: 5V 5-Pin Relay Power 10A (5pcs) (Silver)
SKU: PONS841883
Price: 290 BDT
Availability: InStock

Category: Computers, Components & Accessories

SKU: PONS841883

Seller: Ponno shopping

Tk 251

Tk 290

13% OFF

0 review(s)

Trigger Current (Nominal current) : 70mA
Maximum AC load current: 10A @ 250/125V AC
Maximum DC load current: 10A @ 30/28V DC
Compact 5-pin configuration with plastic moulding
Operating time: 10msec Release time: 5msec
Maximum switching: 300 operating/minute (mechanically)

Call For Order : 09613-800800

Pin Number
Pin Name
Description
1
Coil End 1
Used to trigger(On/Off) the Relay, Normally one end is connected to 5V and the other end to ground
2
Coil End 2
Used to trigger(On/Off) the Relay, Normally one end is connected to 5V and the other end to ground
3
Common (COM)
Common is connected to one End of the Load that is to be controlled
4
Normally Close (NC)
The other end of the load is either connected to NO or NC. If connected to NC the load remains connected before trigger
5
Normally Open (NO)
The other end of the load is either connected to NO or NC. If connected to NO the load remains disconnected before trigger

Trigger Current (Nominal current) : 70mA
Maximum AC load current: 10A @ 250/125V AC
Maximum DC load current: 10A @ 30/28V DC
Compact 5-pin configuration with plastic moulding
Operating time: 10msec Release time: 5msec
Maximum switching: 300 operating/minute (mechanically)
