3.7V 9V 5V 2A Adjustable Step Up 18650 Lithium Battery Charging and Discharge Integrated Module (Silver)

Name: 3.7V 9V 5V 2A Adjustable Step Up 18650 Lithium Battery Charging and Discharge Integrated Module (Silver)
SKU: PONS841543
Price: 250 BDT
Availability: InStock

Category: Battery & Charger

SKU: PONS841543

Seller: Ponno shopping

Tk 71

Tk 250

72% OFF

0 review(s)

3.7V 9V 5V 2A Adjustable Step Up 18650 Lithium Battery Charging and Discharge Integrated Module

Input voltage: 4.5-8V
Output voltage: continuous adjustable 4.3-27V (Counter clockwise to boost voltage)
Charging voltage: 4.2V
Charging current: up to 1A
Discharge current: the maximum 2A
Output reference maximum current: 5V 1.4A, 9V 0.8A, 12V 0.6A
Quiescent current: about 0.5 mA

Call For Order : 09613-800800

3.7V 9V 5V 2A Adjustable Step Up 18650 Lithium Battery Charging and Discharge Integrated Module

Input voltage: 4.5-8V
Output voltage: continuous adjustable 4.3-27V (Counter clockwise to boost voltage)
Charging voltage: 4.2V
Charging current: up to 1A
Discharge current: the maximum 2A
Output reference maximum current: 5V 1.4A, 9V 0.8A, 12V 0.6A
Quiescent current: about 0.5 mA
Overshoot protection: Yes
Over discharge protection: None (also can be said yes, because 2V cut-off boost but does not block the output, output has 2V)
Deadline boost:: 2V, depending on whether added the additional protection board
Size: 3.3 x 2.3 x 0.9cm

3.7V 9V 5V 2A Adjustable Step Up 18650 Lithium Battery Charging and Discharge Integrated Module

Input voltage: 4.5-8V
Output voltage: continuous adjustable 4.3-27V (Counter clockwise to boost voltage)
Charging voltage: 4.2V
Charging current: up to 1A
Discharge current: the maximum 2A
Output reference maximum current: 5V 1.4A, 9V 0.8A, 12V 0.6A
Quiescent current: about 0.5 mA
